It is controlled by a microcomputer and runs fully automatically. It detects the exhaust pressure, temperature and other operating data. Through the joint action of the microcomputer controller, frequency converter and frequency conversion motor, it outputs a constant exhaust pressure for the user. When the air is not used for a long time, it can automatically shut down and restart when the air is restored, thus achieving the purpose of energy saving (frequency conversion model); Chinese and English display, with 12 important indicator warnings; the display screen displays pressure, temperature, maintenance reminders, high temperature and high pressure records of the operation history for maintenance and reference, and can provide manual and automatic control functions to maximize the reliable operation of the air compressor and increase its service life.

Adopt high temperature resistant permanent magnet motor. Motor efficiency is 8% higher than standard VSD motor

and 50% higher than standard base load motor.

World renowned gas-end (gas compression pump head) is specially designed for biogas application with thousands installation worldwide. Special features include:

• Bearings (Copper free, oversized design)
• Wide suction / discharge pressure range, Suction:-0.67bar (vacuum)~ 3.45bar.g; Discharge: 5bar.g~35bar.g)
• Mechanical seal (more reliable and long life than lip seal system)
• In compliance with ATEX2014/34/EU (Zone 1,2);API 619
