Product overview

During underground construction, significant quantities of harmful gases and dust are generated. At excavation sites, the concentration of respirable dust can reach up to 600 mg/m³ . According to the European standard BS 6164-2019, the permissible exposure limits for respirable crystalline silica dust and respirable dust are ≤0.1 mg/m³ and <4 mg/m³ respectively. Respirable crystalline silica is classified as a Group 1 carcinogen by the International Agency for Research on Cancer (IARC), posing severe health risks to on-site workers.

The dust and noxious gas produced are conducive to the equipment operation and maintenance, thus seriously delay the project schedule. Underground space environment management directly affects the construction period, even the whole project. A good engineering route selection, design and engineering management can greatly shorten the construction duration.

The application of ADEKOM high-efficiency VFD energy-saving fans, leak-proof air ducts, deduster on working surface and intelligent control systems can effectively ensure safety, economy and improve overall efficiency.

Technical Parameter
Type RD-600 RD-900 RD-1200 RD-1500 RD-1800 RD-2400 RD-3000
Rated Airflow 600m3/min 900m3/min 1200m3/min 1500m3/min 1800m3/min 2400m3/min 3000m3/min
Fan voltage 380V 3
Specifications power 30kWx2 45kWx2 55kWx2 75kWx2 90kWx2 110kWx2 132kWx2
Filter Specifications Filtration accuracy Removal efficiency of ≥1 μm particles reaches 99.99%.
Reference Applied Cross Section Determine dust extraction aiflow according to duct size and purfication speed requirements.
Dimension

L(m)²W(m)*H(m)

6.7*2.2*2.6 8.4*2.2*2.6 10*2.45*2.7 10*2.45*2.7 12*2.45*2.8 14*2.45*3.0 16*2.45*3.0
Application area
Water diversion, Sewage, Cable, Communication, Gas supply and other municipal utilities comprehensive pipeline projects.
